Rotary Laser Cutting Machine Factory
- 40+ Years of Die-Making Expertise
- Trusted by 5,000+ Clients Over 100 Countries
- Worry-Free After-Sales
Co2 Rotary Laser Cutting System
High-speed CO₂ laser system designed for rotary die boards in corrugated box factories, die makers, and packaging converters. Features a stable body structure, advanced CNC control, and flexible functions for precise and efficient cutting. Supports a wide diameter range from 170mm to 800mm, delivering superior performance compared to traditional methods.
Rotary laser cutting machine YT83 Series
Rotary Laser Cutting Machine for High-Speed Rotary Die Making
YITAI’s rotary laser cutting machine series—designed for rotary die board and rotary plywood cutting—delivers high precision, fast processing, and stable performance for corrugated packaging production. Engineered for rotary die shells, curved plywood, and rotary cutting rules, these CO₂ rotary laser die cutting machines ensure accurate kerf width, smooth curves, and reliable results across long production runs.
| MODEL NO. | YT83-10N/15N/20N | ||
| POWER | 1000W | 1500W | 2000W |
| CUTTING SPEED | 45-50m/h | 65-75m/h | 80-85m/h |
Technical Parameters
| Optical system: | US |
| Machine structure: | Gantry |
| Chiller system: | Made in China |
| Controlling system: | Germany PA |
| Drivingsystem: | Japan high-precision servo motors |
| Transmission system: | Ball screw & Linear guide(TAIWAN) |
| Laser gas requirement: | He, N2, Co2(99.99%) |
| Laser output type: | High power axial flow CO2 laser source |
| The maximum cutting board size: | 170~800*3000mm |
| Re-Positioning precision: | ≤0.02mm |
| Laser cutting thickness: | 0.1-30mm |
| Centrifugal blower: | 1 set |
WHY CHOOSE US ?
Full-Range Precision Die Making Group: Equipment & Consumables
- 40+ Years Taiwan Die Making Expertise
- 33 Specialized Factories Worldwide
- Precision Die Making Machinery for Complete Factory Solutions
- 1,000+ Printing & Die-Making Consumables for Full Service Solution
